Eccentric Drilling Odex 90 For 115mm Casing Tube Overburden Casing Drill Bit

Name: Eccentric Drilling Odex 90 For 115mm Casing Tube Overburden Casing Drill Bit
Brand: MIROC
Price: 1 USD

Best Eccentric Drilling Odex 90 For 115mm Casing Tube Overburden Casing Drill Bit wholesale

Brand Name : MIROC

Model Number : ODEX 90 bit

Certification : ISO9001:2015

Place of Origin : Shangdong,China

MOQ : 5PCS

Price : Negotiation

Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram, D/A

Supply Ability : 20000PCS Per Month

Delivery Time : 10-25Days

Packaging Details : Wooden Case/Plate

Product Name : Overburden drilling system

Application : Construction works , Energy & Mining

Processing Type : Forging

Min.casing ID : 102mm

Max.casing ODr : 115mm

Shank : DHD3.5

Face : Drop Center, Concave, Convex, Flat

Material : Carbon Steel

Button : Spherica,parabolic, Ballistic

Color : Green, Black And Demaned By Customer

Contact Now

Eccentric Drilling Odex 90 Odex Bit For 115mm Casing Tube

Product Description

Eccentric casing drilling system is today’s preferred method for drilling in difficult ground conditions, for example, where there are boulders or loose formations.EDS is the most economical solutions because its ingenious reaming wing the bit is retrievable can be used at the next hole. This is particularly design for shallow holes, as is often the case in water well drilling, geothermal wells and for shallow micro-piling work. EDS is ideal for short holes in consolidated overburden. The component of Eccentric system consists of Pilot bits, Reamer bits, Guide device and casing shoe.

When drilling, the reamer bit will rotate out to enlarge the hole which enough for the casing tube slide down behind the reamer. When reached required depth, the drill pipe will drill to the reverse direction and the reamer bit will retract, it is allowing the whole drilling system to pass through the casing.

Specification:

Casing outer dia.(mm)	Casing thickness(mm)	Ring bit dia.(mm)	Max.dia. of normal bit(mm)	Suitable hammer (inches)	Retrievable
114	10	126	84	3.5	No
		122			Yes
127	10	142	93	3.5	No
		135			Yes
140	10	161	97	4	No
		148			Yes
146	10	165	110	4	No
		154			Yes
168	12	188	127	5	No
		180			Yes
178	12.7	196	131	5	No
		185			Yes
194	12.7	214	145	6	No
		202			Yes
219	12.7	243	170	6	No
		228			Yes
